BASIC: AMD AM5
ZA PROCESORE: AMD RYZEN 9000 & 8000 & 7000 Serija Desktop Procesora
FORMAT: ATX format 30.5 cm x 24.4 cm
VEZNI ČIP: AMD B850
PAMET:
4 x DDR5 DIMM ECC i Non-ECC, Un-buffered Memory 8000+/7600+(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800MHz (ovisno o procesoru) do ukupno 256GB kapaciteta, dual channel i EXtended Profiles for Overclocking, ASUS Enhanced Memory Profile (AEMP) podrška
GRAFIKA: DA – preko APU
RAID: DA
AMD RAIDXpert2 Tehnologija
Ryzen™ 9000 Serija Procesora: RAID 0/1/5/10
Ryzen™ 8000 Serija Procesora: RAID 0/1
Ryzen™ 7000 Serija Procesora: RAID 0/1/10
PROŠIRENJE REŽE:
AMD Ryzen™ 9000 & 7000 Serija Desktop Procesora
1 x PCIe 5.0 x16 slot (podržava x16 mod)
AMD Ryzen™ 8000 Serija Desktop Procesora
1 x PCIe 4.0 x16 slot (podržava x8/x4 mod)
AMD B850 Chipset
1 x PCIe 4.0 x16 slot (podržava x4 mod)
2 x PCIe 3.0 x16 slota (podržava x1 mod)
MREŽNA KARTICA: Realtek 2.5GbE LAN čip (10/100/1000Mbit/2.5Gbit) TUF LANGuard + 2×2 Wi-Fi 6E + Bluetooth® v5.3
ZVUČNA KARTICA: Realtek 7.1 Surround Sound High Definition Audio CODEC
NOTRANJI PRIKLJUČCI:
Fan and Cooling Related
1 × 4-pin CPU Fan header
1 × 4-pin CPU OPT Fan header
1 × 4-pin AIO Pump header
4 × 4-pin Chassis Fan headers
Power Related
1 × 24-pin Main Power connector
1 × 8-pin +12V CPU Power connectors
1 × 4-pin +12V CPU Power connectors
Storage Related
3 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 5Gbps connector (podržava USB Type-C® )
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
3 x USB 2.0 headers support 6 additional USB 2.0 ports
Miscellaneous
3 x Addressable RGB Gen 2 headers
1 x Clear CMOS header
1 x Chassis Intrusion header
1 x COM Port header
1 x Front Panel Audio header (F_AUDIO)
1 x S/PDIF Out header
1 x SPI TPM header (14–1 pin)
1 × 10–1 pin System Panel header
1 x Thunderbolt™ (USB4®) header
SPOLJNJI PRIKLJUČCI:
1 x USB 10Gbps port (1 x USB Type-C®)
3 x USB 10Gbps ports (3 x Type-A)
2 x USB 5Gbps ports (2 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
1 x DisplayPort
1 x HDMI™ port
1 x Wi-Fi modul
1 x Realtek 2.5Gb Ethernet port
3 x Audio jacks
1 x BIOS FlashBack™ button
DODATNO:

ASUS 5X PROTECTION III
- DIGI+ VRM
- LANGuard
- Zaštita od prenapona
- SafeSlot
- Nehrđajući čelik back I/O
ASUS Q-Design
- Q-Antenna
- Q-Dashboard
- Q-DIMM
- Q-LED Core
- Q-Slot
ASUS Thermal Solution
- Fleksibilno M.2 hladnjak
- VRM dizajn hladnjaka
ASUS EZ DIY
- BIOS FlashBack™ button
- BIOS FlashBack™ LED
- Pre-montirani I/O štit
- SafeSlot
Aura Sync
- Addressable RGB Gen 2 headers
ASUS Ekskluzivni Softver
Armoury Crate
- Aura Creator
- Aura Sync
- Fan Xpert 2+
- Ušteda energije
ASUS AI Savetnik
ASUS Driver Hub
ASUS GlideX
TurboV Core
ASUS CPU-Z
Adobe Creative Cloud (Besplatno Isprobavanje)
Norton 360 Deluxe (60 Dana Besplatno Isprobavanje)
WinRAR (40 Dana Besplatno Isprobavanje)
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
- ASUS MyHotkey

Web stranica proizvođača: https://www.asus.com/motherboards-components/motherboards/prime/prime-b850-plus-wifi/
